LEWIS BROTHERS MAUFACTURING INC DB-4
Request Quote
Hi, my name is and I would like to get more information on this LEWIS BROTHERS MAUFACTURING INC DB-4 .
I can be reached by email at or by phone at
.


Part #: DB-4
Mfg: LEWIS BROTHERS MAUFACTURING INC
Category: TRACTOR ATTACHMENTS
Sub-Category: CHICKEN HOUSEKEEPER
Industry: AGRICULTURAL
Machine Size: 60 HP PTO HP MIN
Attachment Size: 69" WORKING WIDTH 165 CU.FT.
List Price: $44,250.00 (not including Freight)
Shipping: Call for Shipping Quote
Shipping Info:
Inventory: DB-4: 0 AFS / 0 QOH / 0 QOO / ISBF
The DB-4 Housekeeper is built for the dedicated one-to-six-house grower who needs power, reliability, and efficiency without the need for total cleanout capability. Designed to perform in tighter house dimensions and operate with tractors as small as 60 HP, the DB-4 delivers big performance in a compact, efficient package. The main reason to choose the DB-4 is simple — it’s for the grower who primarily needs effective de-caking and routine litter maintenance, not full cleanouts every flock. While the DB-4 does not utilize the patented quick-change conveyor system found on other Lewis Brothers models, it still offers the versatility to switch from de-caking to total cleanout with the optional solid bar kit. The DB-4 provides a dependable, cost-effective solution for growers who want proven performance and simplified operation without sacrificing capability.

Housekeeper Dump-Body Model 4

DB-4

  1. Patented conveyor system uses expanded metal bars to effectively clean and sift litter
  2. Superior de-caking capability resulting from installation of shaker rollers
  3. Dump feature allows quick and easy offloading and stockpiling of litter
  4. Fully self-contained hydraulic operating system powered by tractor’s PTO
  5. 12.5L X 6 tires
  6. Optional tandem axle w/ 9.5L X 15 tires
  7. 60HP required PTO horsepower
  8. 165 cubic foot capacity
  9. Indicator light signaling full capacity

Specifications

Working Height69"
Overall Length22.5'
Overall Width84"
Weight6800lbs (empty)
Throat69"
Capacity165 cu. ft.
Tires12.5L x 16
Tires (Tandem Optional)9.5L x 15
Required PTO Horsepower60 HP
Hydraulic OilAW-68
PTO Hydraulic Pump22 gpm
Oil Reservoir Capacity30 gal
