GRAPPLE RAKE ELECTRIC AG TRACTOR
|
|
No auxiliary hydraulics to operate the clamp on a grapple? No problem with Worksaver’s (patent applied for) Electric Sub-Compact Grapple. All you need is a connection to the battery. Engineered for Sub-Compact tractors (up to 32-hp) with a loader to handle debris & so much more. The ESCG-48S and ESCG-48JD are opening possibilities never before available to large and small property owners. 48” Electric grapple for Sub-compact tractors w/loaders with JD hook& pin quick attach (200X, 200CX, D120, H120, H130, D160, 220R). Includes wiring harness & rocker switch to allow installation with connection to tractors battery - Twice the strength with the new actuator
- 2000 LBS of force versus 1000 LBS of force
- Works more like a Hydraulic Cylinder with grip strength
- Speed is the same at 1”/Sec (8 seconds per cycle)
- Actuator uses a Potentiometer to read Current draw
- Eliminated slip clutch and shear pin These were the weak points in the Gen I actuators
- When the actuator hits 38 amps it shuts off
- If the operator leaves the button depressed after the actuator stops and then moves the loader, the actuator will tighten as the load shifts. This results in easier and quicker picking up debris.
- The old actuator had the operator move the loader, tighten, move the loader, tighten and so on until the load was secure.
- The actuator is more robust and more fail safe than the Gen I.
|
